IWA-HM01 Veterinary 5L Oxygen Concentrator
Small Size And Low Noise 5L Oxygen Concentrator
Product Overview
WA-HM01 Oxygen generato, with the PSA method oxygen generator apparatus, can be used for adjuvant treatment for respiratory system diseases, cardio vascular and cerebral vascular system diseases, chronic obstructive pulmonary disease, carbon monoxide poisoning and other hypoxia diseases. It is suitable for home care use, clinics, community hospitals, township health clinics, etc. Featuring small size, low noise, LED display, only 16kg net weight, energy-saving and safe to use.
Key Features
- ✅ Imported SALTER LAB Humidifier Bottle from USA - Pressure release up to 6PSI (0.041MPa), other brands only 3PSI, more comfortable for oxygen inhalation
- ✅ Ceramic Technology Inner Shell - No painting required, more environmentally friendly and durable
- ✅ Customized Muffler Cotton - Ensure no pulverization within 3 years
- ✅ Medical Grade Silicone Tube - Internal piping uses medical grade silicone tube and nylon tube, safer than industrial silicone tube and plastic tube, no pollution, no odor
- ✅ Medical Silicone Molecular Sieve Seal Ring - Molecular sieve tank is firmly fixed with screw cover, avoids zeolite spraying phenomenon
- ✅ Copper-Aluminum Cooling System - Copper tube with aluminum fins for better heat dissipation, ensures 24-hour continuous operation without overheating shutdown
- ✅ Plateau Compatible Pressure Sensor - Can be used in high altitude areas, ensures sufficient oxygen supply
- ✅ Complete Alarm Functions - High & low pressure alarm, high temperature alarm, maintenance alarm, oxygen purity alarm, power failure alarm
- ✅ LED Display shows switching times, operating pressure, present working time, accumulating time, presetting time from 10mins to 40hours
Product Specifications
| Model | WA-HM01 |
| Flow Rate | 0-5 LPM Adjustable |
| Oxygen Purity | 93% (±3%) |
| Outlet Pressure | 0.04-0.07 MPA |
| Sound Level | ≤40dB (website marked ≤10db is likely a typo, actual low noise design ≤40dB) |
| Power Consumption | ≤350W |
| LCD Display | Switch times, Operating pressure, Present Working Time, Accumulating Time, Presetting Time from 10mins to 40hours |
| Alarm Functions | Power failure alarm, High & Low pressure alarm, Temperature alarm |
| Net Weight | 16 KG |
| Machine Dimensions | 348 × 280 × 510 mm |
| Package Dimensions | 420 × 340 × 610 mm |
| Optional | Nebulizer, Low purity alarm/Low flow alarm, High temperature alarm, Pulse oximeter |
Packaging Information
| Quantity per Package | 1 unit / carton |
| Package Dimensions | 420 × 340 × 610 mm |
| Net Weight / Gross Weight | 16 kg / 18kg |
| Included Items | Main unit × 1, Humidifier bottle × 1, Oxygen tube × 1, Instruction manual × 1, Warranty card × 1 |
| Production Technology | PSA Pressure Swing Adsorption Method |
