IWA-HU01 Handheld Urine Analyzer

Veterinary Miniature Handheld Urine Analyzer for Clinical Urinalysis Testing

---

Product Overview

The IWAMED IWA-HU01 Handheld Urine Analyzer is a compact and portable urine testing device specially designed for veterinary clinical use. With its miniature size and lightweight design, it enables quick on-site urine chemistry analysis in animal clinics and field operations. This analyzer provides automatic strip result capture and reporting, delivering reliable semi-quantitative results with high repeatability.

---

Key Features

• ✓ Miniature compact design - Small size, lightweight, easy to carry
• ✓ Dual output options - Screen display or easy printing via handheld printer
• ✓ Automatic result processing - Automatically captures and reports strip results
• ✓ Fast testing speed - Only 70 seconds per test result
• ✓ High repeatability - Reliable semi-quantitative urine chemistry analysis with high repeatability
• ✓ Comprehensive 11-parameter testing - Detects 11 urine biochemical parameters

---

Product Specifications

Product Name	Handheld Urine Analyzer
Model	IWA-HU01
Category	Laboratory Equipment
Detection Parameters	11 parameters
Supported Parameters	LEU, NIT, URO, PRO, pH, BLD, SG, KET, BIL, GLU, VC
Testing Principle	Colorimetry
Display	2.4-inch LCD
Testing Speed	140 tests/hour (continuous mode), 50 tests/hour (single mode)
Data Storage	1000 results
Battery Life	6 hours continuous operation
Printer Support	Wireless thermal printer
Interface	Mini USB
Power Supply	Rechargeable lithium battery
Dimensions	110mm × 68mm × 27mm
Suitable for	Veterinary clinical diagnosis, point-of-care testing

---

Packaging Information

• 1 × IWA-HU01 Handheld Urine Analyzer Main Unit
• 1 × Built-in rechargeable lithium battery
• 1 × Mini USB cable
• 1 × User Manual
• (Optional) 1 × Wireless thermal printer
