IWAMED IWA-CC01 Automatic Urine Analyzer
Automatic Urine Analyzer for Veterinary Use
Product Overview
The IWAMED IWA-CC01 is a high-precision intelligent automatic urine analyzer developed based on modern optics, electronics, computer science and other advanced technologies. It can test multiple items including GLU, BIL, SG, KET, BLD, PRO, URO, NIT, LEU, VC, PH, MAL, CR, UCA with special test strips, suitable for hospitals, community health services, clinics, epidemic prevention stations and family use.
Key Features
- ✅ High Brightness Long Life LED - High brightness white LED, long life, good stability
- ✅ 2.4-inch Color LCD - 2.4-inch color LCD display, supports Chinese and English language optional
- ✅ User-friendly Interface - Easy to use with friendly user interface
- ✅ Optional Unit System - Supports both international and conventional unit systems
- ✅ Automatic Prompt - Automatic character and voice prompt during entire testing process
- ✅ Compatible with multiple test strips - Compatible with 8, 10, 11, 12, 14 parameter test strips (optional based on test strip type)
- ✅ Standard Interface - Standard MicroUSB interface, optional Bluetooth interface
- ✅ Built-in Battery - Built-in rechargeable lithium battery
Product Specifications
| Testing Items | GLU, BIL, SG, KET, BLD, PRO, URO, NIT, LEU, VC, PH, MAL, CR, UCA (optional according to test strip type) |
| Repeatability | CV ≤ 1% |
| Stability | CV ≤ 1% |
| Display | 2.4-inch color LCD display |
| Testing Speed | ≥ 60 tests/hour |
| Data Storage | Stores 500 sample results, can query by test date, sample number and user name |
| Interface | Standard MicroUSB interface, optional Bluetooth interface |
| Power | DC 5V, 1A, built-in rechargeable lithium battery |
| Dimensions | 126 (L) × 73.5 (W) × 30 (H) mm |
| Weight | About 0.18 kg |
Working Environment
- Temperature: 10 ℃ - 30 ℃
- Relative Humidity: ≤ 80%
- Atmospheric Pressure: 76kPa - 106kPa
Storage Environment
- Temperature: -40 ℃ - 55 ℃
- Relative Humidity: ≤ 95%
- Atmospheric Pressure: 76kPa - 106kPa
Packaging Information
- 1 × IWAMED IWA-CC01 automatic urine analyzer main unit
- 1 × Power Charger
- 1 × User Manual
